Anti-Reflective (AR) Coating Line for Solar Glass - Fully Automatic Magnetron Sputtering System
รายละเอียดสินค้า:
| สถานที่กำเนิด: | จีน |
| ชื่อแบรนด์: | Osmanuv |
| ได้รับการรับรอง: | ISO9001 |
| หมายเลขรุ่น: | OSM-GLDM-620T |
| เอกสาร: | film Lamintaing.pdf |
การชำระเงิน:
| จำนวนสั่งซื้อขั้นต่ำ: | 1 ชุด |
|---|---|
| ราคา: | negotiable |
| รายละเอียดการบรรจุ: | กล่องไม้ |
| เวลาการส่งมอบ: | 45 วัน |
| เงื่อนไขการชำระเงิน: | t/t |
| สามารถในการผลิต: | การเจรจาต่อรอง |
|
ข้อมูลรายละเอียด |
|||
| โหมดความดัน: | คู่มือ | พลัง: | 76 กิโลวัตต์ |
|---|---|---|---|
| ความเร็วในการทำงาน: | 12000pieces/h | ความเร็วในการเคลือบสูงสุด: | 3-20ม./นาที |
| ทิศทางของเครื่องจักร: | จากซ้ายไปขวา | มิติโดยรวม: | 6000*1500*1680 มม. |
| พิมพ์: | เครื่องเคลือบแบบม้วน | กรอกลับ: | ไม่จำเป็น |
รายละเอียดสินค้า
Anti-Reflective (AR) Coating Line for Solar Glass - Fully Automatic Magnetron Sputtering System
Composition of Production Line
-
Automated glass loading/unloading system
-
Precision cleaning and surface treatment unit
-
Multi-station magnetron sputtering coating chamber
-
In-situ optical monitoring and thickness control
-
High-temperature annealing and curing section
-
Automated quality inspection station
-
Integrated dust-free environmental control
-
Intelligent manufacturing execution system (MES)
Product Description
This turnkey AR coating production line specializes in depositing high-efficiency anti-reflective coatings on photovoltaic glass through advanced magnetron sputtering technology. The system significantly enhances light transmittance while providing excellent durability and weather resistance. The entire line is fully customizable to accommodate specific production requirements, glass dimensions, and coating performance targets.
Technical Parameters
| Parameter | Standard Specification | Customization Options |
|---|---|---|
| Max Substrate Size | 2300 × 1300 mm | Customizable up to 2800 × 1600 mm |
| Production Capacity | 100-200 panels/hour | Adjustable line speed |
| Coating Uniformity | ≤ ±2.5% | Optimizable to ≤ ±1.5% |
| Transmittance Increase | ≥ 2.8% | Custom performance targets |
| Power Consumption | 200-400 kW | Energy-efficient configurations |
| Vacuum Level | 5.0 × 10⁻⁵ Pa | Higher vacuum options available |
| Control System | Siemens/Allen-Bradley PLC | Multi-language interface |
| Coating Materials | SiO₂, TiO₂, Nb₂O₅, etc. | Custom target material selection |
Application
-
Monocrystalline/Polycrystalline PV modules
-
BIPV (Building Integrated Photovoltaics)
-
Solar greenhouse and agricultural applications
-
High-efficiency double-glass modules
-
Specialized optical and display glass
Customization
We provide completely customizable solutions including:
-
Tailored glass size handling capabilities
-
Specific coating stack design and optimization
-
Integration with existing factory automation systems
-
Customized target configuration and material selection
-
Specialized testing and quality control requirements
Feature
-
Advanced Process Control: Real-time optical monitoring and automatic adjustment
-
High Efficiency: Multi-target continuous deposition technology
-
Energy Saving: Heat recovery and power management system
-
Smart Manufacturing: IoT-enabled remote monitoring and predictive maintenance
-
Environmentally Friendly: Low emissions and sustainable operation
Support and Services
-
Turnkey project implementation
-
24-month warranty on main components
-
Remote diagnostic and technical support
-
On-site installation and commissioning
-
Comprehensive operator training program
-
Spare parts supply and management
-
Process optimization and upgrade services
Packing and Shipping
-
Heavy-duty export packaging
-
Climate-controlled container shipping
-
Professional logistics management
-
Worldwide delivery service
-
On-site installation supervision
FAQ
Q: What is the typical delivery time for a customized production line?
A: Standard delivery is 20-24 weeks, with customized configurations requiring 24-30 weeks.
Q: Can the line process different glass thicknesses?
A: Yes, the system is customizable to handle glass thicknesses from 2.0mm to 6.0mm.
Q: What coating performance can be achieved?
A: Typically achieves 2.8%-3.2% transmittance increase, with customizable performance targets.
Q: Do you provide process validation services?
A: Yes, we offer complete process validation and optimization services.
Q: What kind of training is included?
A: We provide comprehensive training covering operation, maintenance, and process control.
Q: Can the line be upgraded in the future?
A: Yes, the modular design allows for future upgrades and customization.
Q: What is the power requirement?
A: Standard 380V/50Hz/3Phase, customizable to local power standards.
